丰富多样的按钮开关

  • 丰富多样的按钮开关
  • 取得 ENEC、UL、CSA 认可。认可和等级随功能可能不同 - 详情参考技术数据。提供高功率版本
  • 8300、8301、8350、8351 系列亦可提供 IP66 面板密封防破坏版本，配备不锈钢机身、按钮和外框
  • 单刀和双刀版本机身尺寸相同，带有多种切换功能
  • 可选择：
  • - 端接方式：6.3 x 0.8 QC、4.8 x 0.8 QC、直角 4.8 x 0.8 QC、2.8 x 0.8 翼片、焊接扣环、PCB 安装、PCB 安装双引脚（可添加 PCB 安装模拟端子，为开关机身提供额外的机械支持 - 详情请联系销售部）
  • - 机身颜色：黑色、白色
  • - 机身样式：标准、Softline。耐候外壳选项
  • - 执行机构按钮：标准、方形、半圆形、小圆形、大圆形、平滑弧形、活塞式、开槽（搭配定制卡扣式按钮）。平滑弧形和大圆形执行机构为光面，其他均为哑光面。8300、8301、8350、8351
  • - 光源：所有类型的执行机构可发光，可选择红色、琥珀色、绿色、透明，使用 12V 或 24V 钨丝灯、125V 或 250V 氖灯（可提供其他照明电压）。带独立光源的开关版本（8355、8356 系列）仅提供方形、半圆形或活塞式执行机构
  • - 图例：除开槽版本外，所有执行机构类型均可无印刷，或印刷为黑色或白色，可选择多种图例
  • 亦可提供：L167 卡扣保护盖（仅适用于标准或平滑弧形执行机构版本）
  • BioCote 添加剂选择，利用 BioCote 银离子技术使模压组件具备抗菌性能
  • 如需全系列图例的详情，或大批量定制机身、执行机构和图例颜色的信息，请联系销售部
产品下载 Product Certificates

Part number builder

Make one selection from each category to define part number



  • Termination



    Select

    1

    A - 4.8 x 0.8 QC Right Angle

    C - 6.3 x 0.8 QC

    H - 4.8 x 0.8 QC

    K - 2.8 x 0.8 Tab

    T - Solder Lug

    V - PCB Mount Dual Pin

    Extra dummy PCB Mount terminals can be added for additional mechanical support to switch body - contact Sales for details

    X - PCB Mount

    Extra dummy PCB Mount terminals can be added for additional mechanical support to switch body - contact Sales for details

  • Switching



    Select

    2

    8300 - Single Pole ON OFF

    8301 - Single Pole ON OFF (Momentary ON)

    8303 - Single Pole ON OFF Illuminated

    8304 - Single Pole ON OFF (Momentary ON) Illuminated

    8350 - Double Pole ON OFF

    8351 - Double Pole ON OFF (Momentary ON)

    8353 - Double Pole ON OFF Illuminated

    8354 - Double Pole ON OFF (Momentary ON) Illuminated

    8355 - SP ON OFF With Switched Iso Illumination

    With Switched Isolated Illumination. Only available when Square Button (C), Radiused Button (E), Plunger (M) Actuator selected

    8356 - SP ON OFF With Unswitched Iso Illumination

    With Unswitched Isolated Illumination. Only available when Square Button (C), Radiused Button (E), Plunger (M) Actuator selected

  • Actuator



    Select

    3

    Actuators A, C, E, F, M are Matt Finish, Actuators J, D are Gloss Finish. Wide range of other Actuator types available - contact Sales for details

    A - Standard Button

    Not available when 8355, 8356 Series Switching selected

    C - Square Button

    D - Large Round Button

    Not available when 8355, 8356 Series Switching selected

    E - Radiused Button

    F - Small Round Button

    Not available when 8355, 8356 Series Switching selected

    H - Slotted

    For snap-in custom buttons. Not available when Illuminated Switching (8303, 8304, 8353, 8354, 8355, 8356 Series) selected

    J - Smooth Curved Button

    Not available when 8355, 8356 Series Switching selected

    M - Plunger

  • Body/Bezel



    Select

    4

    B - Standard Body/Bezel

    E - Softline Body With Radiused Bezel

  • Body Colour



    Select

    5

    B - Black

    W - White

  • Actuator Colour



    Select

    6

    Options available for all Switching selections

    R - Red/Red Illuminated

    Must select Illumination when Illuminated Switching (8303, 8304, 8353, 8354, 8355, 8356 Series) selected. Not available when Slotted (H) Actuator selected

    Options available for non-Illuminated Switching (8300, 8301, 8350, 8351 Series) selections only

    B - Black

    Must select when Slotted (H) Actuator selected

    W - White

    Not available when Slotted (H) Actuator selected

    Options available for Illuminated Switching (8303, 8304, 8353, 8354, 8355, 8356 Series) selections only. Must select Illumination

    A - Amber Illuminated

    C - Clear Illuminated

    G - Green Illuminated

  • Illumination



    Select

    7

    Select (Not Applicable) unless Illuminated Switching (8303, 8304, 8353, 8354, 8355, 8356 Series) selected when Illumination must be selected

    (Not Applicable)

    Must select when non-Illuminated Switching (8300, 8301, 8350, 8351 Series) selected

    2 - 125V Neon

    3 - 250V Neon

    7 - 12V Filament

    8 - 24V Filament

  • Legend



    Select

    8

    Many other Legends available. Please contact Sales for details of the full range

    Blank/Not Applicable

    No Legend required, or not available for selected Actuator. Must select when Slotted (H) Actuator selected

    1152 - EN1152

    Must select Legend Colour

    1153 - EN1153 - Lamp Horizontal

    Must select Legend Colour

  • Legend Colour



    Select

    9

    Select (Not Applicable) unless Legend selected when Legend Colour must be selected

    (Not Applicable)

    No Legend Colour required - no Legend selected

    B - Black

    W - White

  • Cover



    Select

    10

    None/Not Applicable

    No cover required or no cover available for selected Actuator

    L167 - Snap On Cover

    Only available when Standard Button (A) or Smooth Curved Button (J) Actuator selected

  • Power



    Select

    11

    Standard

    Standard power rating

    H - High Power

    12(12)A 250VAC switch rating; see Technical Data for more details

  • BioCote



    Select

    12

    No BioCote/Not Applicable

    Without BioCote Antimicrobial Additive

    B - With BioCote

    Moulded components have BioCote additive with antimicrobial properties using BioCote silver ion technology
