Horizontal PEM C14 Inlet Sheet F Non Shuttered Outlet PX0575 PX0695
BZH09 / BZH10 Series
- Horizontal Power Entry Module 95.6mm
- C14 Cold Condition Inlet (PX0575) combined with choice of Sheet F Shuttered (PX0783) or Non-Shuttered (PX0695) Outlet:
- Part codes prefixed BZH17, BZH18: Shuttered Outlet
- Part codes prefixed BZH09, BZH10: Non-Shuttered Outlet
- Choice of Termination depending on part code:
- Part codes prefixed BZH09, BZH17: 6.3mm Tab
- Part codes prefixed BZH10, BZH18: 2.8mm Tab
- Choice of mains filter depending on part code:
- Part codes containing /Z0000 are unfiltered
- Choice of mains filter options (part codes containing codes starting /A)
- Choice of other options as specified by individual part code, including switches, indicators
Configure this product using product options below and find a distributor
Other Products In This Series:
